Truck Reflective Tape for Conspicuity Marking (ECE 104 / DOT-C2 Ready)

Increase nighttime visibility and outline vehicle contours with microprismatic metallized truck reflective tape. Supplied in 50mm (5cm) x 45.7m rolls with PSA self-adhesive and release liner for fast, clean application on common truck and trailer surfaces.

This tape is widely used for trucks, trailers, buses and commercial vehicles where high-visibility marking is required.

Why B2B Buyers Choose This Tape

• High visibility outline marking: Microprismatic metallized construction helps return light toward the source for stronger conspicuity.

• Waterproof for outdoor transport use: Built for wet weather exposure and road environments.

• Fast installation with PSA: Pressure-sensitive adhesive (PSA) + release liner simplifies positioning and application.

• Multi-surface compatibility: Suitable for aluminum, plastic and metal substrates used on vehicle bodies.

• Color options for standard layouts: Red / Yellow / White options for rear/side/outline schemes (layout varies by market).

Specifications

Material Statement (Choose One for Your Internal Spec)

Your current page references PET and PMMA in different sections. To avoid confusion in purchasing documents, we recommend confirming one material statement for your RFQ:

• Option A: PET-based microprismatic metallized reflective tape

• Option B: PMMA microprismatic construction (with PSA + release liner)

Tip: If you tell us the market and the document format you need, we can align the final datasheet wording to your procurement standard.

Which Standard Do You Need? (ECE 104 vs DOT-C2)

Different regions purchase conspicuity marking tape under different frameworks:

• EU/UK projects: Buyers commonly request ECE Regulation No.104 documentation and the correct class/marking for enforcement.

• North America projects: Buyers often specify DOT-C2 / FMVSS 108 conspicuity tape. "DOT-C2" is used as a manufacturer certification marking for reflective tape ≥50mm (2 inch) wide under the relevant standard.

RFQ Tip: Tell us your target market (EU/UK or North America) + vehicle type + required documents, and we will recommend the correct configuration and a layout suggestion.

Applications by Vehicle Type

This tape is suitable for common commercial vehicle marking needs:

• Truck bodies: side and rear contour marking

• Trailers: rigid trailers, curtain siders, tankers (layout depends on local rules)

• Buses & commercial vans: outline and visibility enhancement

If you provide photos or drawings of your vehicle body structure, we can suggest the most practical placement plan for installation teams.

Quantity Estimator

Use this quick method to estimate how many rolls you may need:

1. Measure your vehicle effective marking length (single side length, rear width, key outlines).

2. Decide whether you need continuous outline or segmented coverage (depends on local enforcement / customer requirements).

3. Convert total required length into rolls using 45.7m per roll.

Example (simple budgeting):
If your total planned marking length is ~180m, you'll need about 4 rolls (180 ÷ 45.7 ≈ 3.94).
Final roll count depends on layout, overlaps, corners, and waste allowance.

Installation Guide (How to Apply Reflective Tape Correctly)

Proper installation determines adhesion strength and service consistency.

Recommended Conditions

• Apply when the surface is clean, dry, and within a practical temperature range; many industry application guides recommend about 10–38°C for PSA reflective markings.

• Avoid applying to dusty, oily, wet, or freshly painted surfaces.

Step-by-Step Application

1. Surface preparation: Remove dust, grease, wax and moisture; dry completely.

2. Layout marking: Use masking tape or chalk line to pre-align the tape route.

3. Apply gradually: Peel back the release liner slowly and apply from one end without stretching.

4. Pressure is key: Use a roller/squeegee and press firmly across the full width to activate PSA bonding.

5. Corners & seams: Cut cleanly at seams or deep grooves instead of bridging large gaps.

6. After application: Avoid washing or heavy abrasion immediately; allow adhesive to set.

Quality, Documentation & Bulk Supply

We support fleet operators, body builders, and distributors with:

• Bulk production and stable supply for repeat orders

• Batch traceability and consistent roll labeling

• Documentation pack based on your required market and compliance needs

• OEM / private label packaging and SKU mapping for distributors

RFQ Checklist

To quote quickly, please send:

1. Target market: EU/UK (ECE 104) or North America (DOT-C2/FM VSS 108)

2. Vehicle type: truck / trailer / bus

3. Body type: rigid / curtain / tanker (if trailer)

4. Color(s): red / yellow / white

5. Roll spec: 50mm x 45.7m (or custom)

6. Substrate: aluminum / metal / plastic + surface condition

7. Adhesive preference: standard PSA / high-tack / low-temp

8. Quantity (rolls) + destination port/zip + required lead time

9. Required documents: COA/COC, labeling, test reports (if applicable)

FAQ

Q1: What is the standard size of this truck reflective tape?
A: The standard roll is 5cm x 45.7m (50mm x 45.7m).

Q2: Is it self-adhesive and does it include a release liner?
A: Yes. It uses PSA self-adhesive and includes a release liner.

Q3: What surfaces can it be applied to?
A: It is specified for aluminum, plastic and metal. Proper cleaning and pressure application are important.

Q4: Is it waterproof for outdoor use?
A: Yes, it is listed as waterproof and designed for vehicle marking applications.

Q5: What is the reflective construction?
A: Micro prismatic metallized construction for high visibility.

Q6: What is a good temperature range for applying PSA reflective tape?
A: Many application guides recommend applying around 10–38°C and pressing firmly with a roller/squeegee to activate PSA bonding.
